Rubber Interlocking Tile Making Machine

Certification
China Qingdao Honghesheng Industry Co., Ltd. certification
I'm Online Chat Now

Rubber Interlocking Tile Making Machine

Rubber Interlocking Tile Making Machine
Rubber Interlocking Tile Making Machine Rubber Interlocking Tile Making Machine Rubber Interlocking Tile Making Machine Rubber Interlocking Tile Making Machine Rubber Interlocking Tile Making Machine Rubber Interlocking Tile Making Machine

Large Image :  Rubber Interlocking Tile Making Machine

Product Details:
Place of Origin: CHINA
Brand Name: HHS
Certification: CE/ISO
Model Number: XLB-550X550X4
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD:4000-20000 /SET
Packaging Details: wood package/20-40 gp
Payment Terms: D/A, L/C, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets/month

Rubber Interlocking Tile Making Machine

Description
Heating Platen Size: 550X550*4 Mold Closing ForceF: 100/120/160T
Plate Clearance: 150-300mm Working Layers: 1
Motor Power: 5.5/7.5KW Overall Dimension: 2200X900X2200mm
Weight: 4000KG Type: Vulcanizer,tile Machine
Color: Blue,Customizable Power Source: Hydraulic
Usage: Rubber Tile From Waste Tyre Granule, Glue, Colour Keyword: Tile Vulcanizing Press
High Light:

Rubber Interlocking Tile Making Machine

,

550*550mm Tile Making Machine

,

Crumb Rubber Tile Press

XLB-550*550*4 Rubber Interlocking Tile Making Machine/Crumb Rubber Tile Press



product description



Rubber Mixer Machine.

This machine is mainly used to stir the granules with glue and pigment to be different types rubber compound for the next vulcanization



Rubber Tiles Machine

This machine is used to heat , vulcanize and solidify the rubber compound from mixer machine to be 500*500mm rubber tiles .This machine needs totally 8 set molds . One set molds includes one top mold and two bottom mold . As showed in picture , the machine is equipped with 8 set manual type adjustable rail device , which is used to push mold in and out for easy operation

1. High speed open/close molds, high production efficiency

2. Automatic in/out mold and ejector device, low labor strength

3. Optional normal valve or proportional valve, advanced oil way matching, reduce energy consumption

4. The electric system adopt PLC programming control, which is easy to be operated

Technical Parameters



Model
XLB-550*550*1/50
XLB-550*550*4/50T
XLB-1080*1080/120t
mold closing force
50
50
120
plate size
550*550
550*550
550*550
working layer
1
4
1
daylight
150mm
150mm
150mm
stroke
150mm
600mm
150mm
control
automatic
automatic
automatic









 Detailed Pictures



Rubber Interlocking Tile Making Machine 0



Rubber Interlocking Tile Making Machine 1Rubber Interlocking Tile Making Machine 2Rubber Interlocking Tile Making Machine 3Rubber Interlocking Tile Making Machine 4Rubber Interlocking Tile Making Machine 5Rubber Interlocking Tile Making Machine 6Rubber Interlocking Tile Making Machine 7Rubber Interlocking Tile Making Machine 8



Total Vulcanization Solution

we have been specializing in providing hydraulic press machine since our establishment in 2004.

We provide a wide range of vulcanizing hot press, ranging from 20 to 10,000 tons mostly made-to-order products.

We provide turnkey solution and technical service, for complete machinery installation and production line planning. Our range of products include:

1.Upstroke Type XLB-550*550*1 /50 Ton Rubber Tile Press

2.Upstroke Type XLB-550*550*4 /50 Ton Rubber Tile Press

3.Upstroke XLB-1080*108081/120Ton Rubber Tile Press Machine

4.Down Stroke XLB-1300*1250 Rubber Tile Press Machine

Rubber Interlocking Tile Making Machine 9



Rubber Tile Mold

Mold is used to control size , shape and pattern of final rubber flooring tiles , we can customize the mold according to your need

Rubber Interlocking Tile Making Machine 10Rubber Interlocking Tile Making Machine 11Rubber Interlocking Tile Making Machine 12Rubber Interlocking Tile Making Machine 13



Rubber Interlocking Tile Making Machine 14









Rubber Interlocking Tile Making Machine 15

Rubber Interlocking Tile Making Machine 16Rubber Interlocking Tile Making Machine 17Rubber Interlocking Tile Making Machine 18
