Product Details:
|
| Place Of Origin: | Shandong, China | Condition: | New |
|---|---|---|---|
| Batch Time(times/hour):: | 10 Times/hour | Total Capacity(L): | 55L |
| Marketing Type: | New Product 2021 | Warranty: | 3 Year |
| Core Components: | PLC, Engine, Bearing, Gearbox, Motor, Pressure Vessel, Gear, Pum | Brand Name: | HHS |
| Voltage: | 380V,Customer's Request,380V/50HZ | Power(w): | 75KW |
| Type: | Rubber Kneader,Electric Heating Water Cooling | Color: | Orange,Blue Or Green,customized |
| Application: | Rubber / Plastic Mixing,Mixing Rubber Or Press Rubber Sheet | After-sales Service Provided: | Engineers Available To Service Machinery Overseas |
| Weight: | 7800KG | Dimension(l*w*h): | 3200*1900*2880mm |
| High Light: | EVA Rubber Kneader Machine 75 Liter,Rubber Kneader Machine 75L,110000W Rubber Mixing Banbury Machine |
||
2. Machine Parameters:
| Model |
X(S)N-55 |
X(S)N-75X30 |
|
Total volume of mixing chamber |
125L | 180L |
|
Working volume of mixing chamber |
55L | 75L |
|
Driving motor power |
75KW | 110KW |
|
Tilting motor power |
2.2KW | 4KW |
| Tilting angle | 140° | 140° |
|
Rotational speed of the rotor (front/rear) |
30/24.5 r/min |
30/24.5 r/min |
|
Pressure of compressed air |
0.6-0.8MPa | 0.6-08MPa |
|
Capacity of compressed air |
≥1.0m³/min | ≥1.0m³/min |
|
Pressure of cooling water |
0.3-0.4MPa | 0.3-0.4MPa |
|
Pressure of heating steam (plastic mixing) |
0.5-0.8Mpa | 0.5-0.8Mpa |
|
Overall dimension |
3280X1930 X3070mm |
3330X2620 X3340mm |
| Weight | 7800Kg | 10500Kg |
