C-frame rubber tread plate vulcanizing press machine

C-frame rubber tread plate vulcanizing press machine
C-frame rubber tread plate vulcanizing press machine C-frame rubber tread plate vulcanizing press machine C-frame rubber tread plate vulcanizing press machine C-frame rubber tread plate vulcanizing press machine C-frame rubber tread plate vulcanizing press machine

Large Image :  C-frame rubber tread plate vulcanizing press machine

Product Details:
Place of Origin: Qingdao Shangdong
Brand Name: HHS
Certification: CE
Model Number: XLB-2100X2100
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD 50000
Packaging Details: Wooden cases / Containers, etc
Delivery Time: 15-30 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60 sets/Year
Contact Now

C-frame rubber tread plate vulcanizing press machine

Description
Type: Vulcanizer Colour: All Colour
Voltage: Customized Power(W): 11KW*2
Temperature: Max 300 Degree Working Layers: 1-4layers
Plates: 300-2100mm Hot Plates Material: Q-235 Material.
Heating: Electricity , Steam Heating , Conduction Oil Heating . Weight: 30000 Kg

1. Product Application

Rubber vulcanizing press is used for vulcanizing various kinds of rubber and plastic mould products as well as
non-mould products. And it can make tyre, O-rings, rubber floor tiles, slippers and other rubber products.

2. Product Paramenters



Model
XLB-800*800
XLB-1000*1000
XLB-2100*2100

mold closing force
160 ton
200 ton
2000 ton

plate size
800*800mm
1000*1000mm
2100*2100mm

quantity of cylinder
1 set
1 set
1 set

piston diameter
300mm
380mm
500mm

working layer
1
1
1

daylight
300mm
300mm
450mm

unit area pressure
2.5 Mpa
2.0Mpa
4.53Mpa

Main motor
3 kw
5.5 kw
11kw*2

machine weight
about 4000 kg
about 5800kg
about 40000 kg

C-frame rubber tread plate vulcanizing press machine 0C-frame rubber tread plate vulcanizing press machine 1C-frame rubber tread plate vulcanizing press machine 2C-frame rubber tread plate vulcanizing press machine 3C-frame rubber tread plate vulcanizing press machine 4C-frame rubber tread plate vulcanizing press machine 5



C-frame rubber tread plate vulcanizing press machine 6













C-frame rubber tread plate vulcanizing press machine 7C-frame rubber tread plate vulcanizing press machine 8C-frame rubber tread plate vulcanizing press machine 9C-frame rubber tread plate vulcanizing press machine 10
