Long Press Large Rubber truck tread Vulcanizing Press 1200*2700mm 2000*2500mm

long press large rubber truck tread vulcanizing press

Main application

Specifications

1. Professional manufacturer of curing machine
2. High quality plate press, Large clamping force
3. competitive price

1. High quality plate press
2. Frame and column type
3. Beautiful modeling
4. Compact structure
5. competitive price
6. High speed open/close mold, high production efficiency, protect mold.
7. Adopt new sealing material, excellent seal and long life.
8. Matching advanced oil way, reduce energy consumption.
9. Its structure is simple and application is wide.

It is easy to be operated. This vulcanizing machine is used for all kinds of vulcanizing mould, rubber and plastic mould products, and non-mould products.
Being a column structure and downward pressing type, the heating plate opens by the self-weight of the heating plate, platform and plunger. The rising of the plunger makes the heating plate close while the hydraulic oil provides the pressure.

This engine base is combined together with the cylinder and base frame, which is made of ductile iron to increase the cylinder intensity and a brad ability. The cylinder is fitted with the sealing washer made of the oil-resisting rubber for the sealing purpose.

By moving the operational handle of the control valve to the two different positions, the heating plate can open and close.
It uses the electric pipe for heating, thus makes the workshop clean with easy and reliable operation.

1. Professional manufacturer of curing machine
2. High quality plate press, Large clamping force
3. Completive price, Compact structure
4. High speed open/close mold, high production efficiency, protect mold.
5. Matching advanced oil way, reduce energy consumption.
6. Its structure is simple and application is wide. It is easy to be operated.

Technical data
