Product Details:
|
| Voltage: | 50L/80L | ||
|---|---|---|---|
| High Light: | ASTM Air Ventilation Aging Testing Chamber,SUS304 Aging Testing Chamber |
||
Electric Air Ventilation Aging Testing Chamber HZ-2010
Equipment summary:
The Electric Air Ventilation aging testing chamberis used to test the material characteristic of wire type, skin type, plastic, rubber, cloth. Equiped with a special ventilation regulator to maintain the fresh air inside
when heating. This testing machine is designed with sophisticated air-displacement adjustment device and a
digital voltage meter, current meter, watt-hours, the timer can be used to measure the air replacement rate.
Horizontal circulatory air supply system and both sides of airflow regulator can ensure the internal temperature
uniformity and stability.
Corresponding standard:
Accord with ASTM D5423-9R2005-Type ovenand ASTMD 5374-93(2005) UL-1581GBVDEJISIEC
Applicable industries:
TheElectric Air Ventilation aging testing chamber used to test the material heat-resisting for polymer materials (plastics, plastic) and electrical insulation materials, such as: wire and cable sheathing, heat-shrinkable tubing, rubber or PVC materials.
Technical parameters:
| Model | HZ-2010 |
| Testing space | about 45*50*45cm |
| Temperature | RT~200, resolution: 0.1 degree,accuracy: 0.5 degree. |
| Rotation | 0~10 or 10~200 time/H |
| Ventilation adjusted | Auto-tuning type |
| Ventilation system | Using voltage regulator to change the volume of air |
| Built-in circulating air system | ensure the temperature uniformly 1%. |
| Mateiral | SUS# 304 stainless steel |
| Protector | over-temperature breaker |
| sensor | high-accuray PT100 thermocouple. temperature fluctuation 0.5% |
| inside size | 50*40 * 50 cm(L*W*H) |
| outside size | 120* 65 *134 cm.(L*D*H) |
| insolation | 80mm rock wool. |
| Count the volume of air | formula for Japan JIS7212 |
Main feature:
TheElectric Air Ventilation aging testing chamber used to study the rubber that is heated under the rotary mode in a fixed period. Tested 1 day at 70°c in it ,theoretically equivalent to 6 months exposed in the outside atmosphere. The oven is equipped with motor-driven rotary disk,hot-air circulation system that ensure uniform distribution of temperature. Reference to ASTM, JIS, GB and other testing specifications.
