Product Details:
|
| Voltage: | 50L/80L | ||
|---|---|---|---|
| High Light: | Ozone Accelerating Aging Test Chamber,ASTM Aging Test Chamber,50L Accelerated Aging Chamber |
||
Electric Air Ventilation Aging Testing Chamber HZ-2010
Ozone Accelerating Aging Test Chamber,
ASTM Rubber Plastic Ozone Aging Test Resistance Machine Factory
Applications:
The Ozone aging test chamber is mainly suitable for polymer materials and products (rubber) of the resistance to ozone aging performance test. Ozone content in the atmosphere is very low, but it is the main factors of polymer materials aging. Ozone aging test chamber simulating and strengthen the ozone condition in the atmosphere, get approximate to actual use or reproduction of the test results in a short time. The study of ozone effect regulation to rubber products, quickly identify and evaluate rubber materials resistance to ozone and antiozonant protection efficiency method,and then take effective aging proof measures to improve the service life of rubber products.
The Environment Ozone Aging Test Chamber is mainly adopted for rubber products testing such as vulcanized rubber, thermoplastic rubber, cable insulation sheathing products, intermittent static tensile dynamic tensile deformation, or deformation under dynamic stretching and static stretching alternating, confined to light with constant ozone concentration in the air and constant temperature chamber exposed to detection, scheduled on the specimen occurred from the specimen surface cracking or other properties of the degree of change, resistance to ozone in order to assess the rubber aging properties.
CONTROL SYSTEM
1, With imported micro-computer LCD controller to control the temperature.
2, PID control
3, With auto calculation function to reduce the setting inconvenience.
4, Heater: fin type radiator pipe nickel-chromium alloy u-shaped heater, auto calculate with high accuracy PID + SSR control
5, Temperature measurement: SUS#304, PT 100
Speficiations:
| Model Selection | ||||||
| Model | CY80 | CY150 | CY225 | CY408 | CY800 | CY1000 |
| Inner size W*H*D(cm) | 40*50*40 | 50*60*50 | 50*75*60 | 60*85*80 | 80*100*100 | 100*100*100 |
| Outer size W*H*D(cm) | 85*140*95 | 95*150*115 | 95*165*115 | 105*175*135 | 145*190*135 | 155*195*150 |
| Inner material | SUS 304 stainless steel | |||||
| Temperature range | RT+10°C~60°C | |||||
| Temperature deviation | ±0.5°C (no load) | |||||
| Temperature uniformity | ±2°C (no load) | |||||
| Ozone concentration range | 0~500pphm (or custom made) | |||||
|
Ozone concentration deviation |
10% | |||||
| Sample rack speed | 360 degree rotating sample holder | |||||
| Controller | Touch screen programmable controller | |||||
| Ozone generator | using voltage silent discharge tube produce ozone | |||||
Features:
1, Internal material is imported high quality mirror stainless steel plate.
2, External material adopts stainless steel
3, Insulation material: high-density glass fiber
4, Use long axial fan motor and high and low temperature resistant aluminum alloy wing type wind turbines to force vertical air circulation.
5, Chamber door adopts double layer high and low temperature resistant silicone seal ensure the airtight test area.
6, Chamber bottom has high quality universal wheel and fixed foot cup.
7, Observation window uses multilayer hollow tempered glass.
8, Exhaust system: exhaust the high concentration ozone from the test chamber to avoid to poison.
Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…
Q: Are you a manufacturer or traiding company?
A: We are the manufacturer. We have our own plant,worker and techniques research developing department.
2 .Q: Where is your factory located? How can I visit there?
A: Our factory add is Tieshan industrial Park, Jiaonan, Qingdao, Shandong province, China.
Nearest airport is Qingdao liuting international airport
Kindly send plane information in advance, so that we can pick you up at the airport, and book hotels as you require.
3. Q: What are your hot sale machine?
A: Our rubber and plastic machines are popular in the foriengn market. And main products are tyre recyling plant and other machine.
4. Q: How does your factory do regarding quality control?
A: Quality is priority and we have our own quality control department. We win make a strick inspectin before the machines leave the factory.
5 .Q: Are the techncal parameter is fixed?
A: Basically, each model corresponding to the related machine. But we can design different type machine according to the client’s requirement.
6 How to send us your enquiry? Kindly tell me answer
-1 what is your EVA sheet width ?
-2 Leave your cellphong? Skype? whatsApp?viber? so that we can talk efficiently
Contact Person: Miss. Sophie
Tel: +8613573826806
