Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding

Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding
Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding
Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding

Large Image :  Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding

Product Details:
Place of Origin: Qingdao Shangdong
Brand Name: HHS
Certification: CE
Model Number: XLB350-600
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD2000-3000
Packaging Details: standard wood package or based on clients request
Delivery Time: 15-30 work days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 60sets/Year
Contact Now

Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding

Description
Type: Vulcanizer Colour: All Colour
Voltage: Customized Power(W): 30KW
Temperature: Max 300 Degree Working Layers: 1-4layers
Plates: 300-2100mm Hot Plates Material: Q-235 Material.
Heating: Electricity , Steam Heating , Conduction Oil Heating .
High Light:

Brake Disc Pad Hydraulic Press Machine

,

100T Hydraulic Press Machine

,

Same Density Hot Press Molding Machine

Brake Pad Making Hydraulic Press Machine 100 Ton To 300 Ton /Brake Disc Pad'S Hot Press Same Density Molding Machine

This machine can save both labor and time, female can operate two sets of 300T easily.
High precision:This machine is special for brake pad of cars and motor bikes. Low energy consumption, low noise ,low oil temperature. The main hydro-cylinder adopted no flange structure to improve the leak resistance performance. The high hardness alloy steel used for the main piston rod to increase the wear resistance. The totally enclosed structure for the oil box and electric box are dust-proof.
Advanced Function: Loading the steel sheet and the powder of the brake pad are done out of the machine to ensure the operation safety. During the pressing, the middle mould will be locked automatically to avoid the leaking of the material. And it has the function of separating automatically, The bottom mold, the middle mold, and the top mold can move automatically, which will make full use of the mold area, improve the production and save labor.


Technical Parameters

Description Unit Item No:SGSCP-X
120T 200T 300T 400T
Max Pressure Ton 120 200 300 400
Max Stroke mm 300 350 350 400
Mold Sizs mm 320*450 500*500 500*500 600*500
open height mm 350 400 450 500
motor power kw 4 4 4 7.5
heating power kw 6.4 9.6 9.6 12
working table height mm 800-900 800-900 800-900

800-900



Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 0



Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 1Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 2



Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 3









Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 4Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 5Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 6Brake Disc Pad Hydraulic Press Machine 100 Ton 300T Same Density Molding 7
