Product Details:
Place of Origin: CHINA
Brand Name: HHS
Certification: CE ISO
Model Number: HD-800-2600
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD:2000-20000 /SET
Packaging Details: wood package /20-40 container
Delivery Time: 20 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets/month

Rubber Tyre Pressure Vessel Vulcanization Tank 2000mm 2600mm

Description
Place Of Origin: Shandong, China Max Working Press: 0.8 MPa
Warranty: 1 Years Core Components: PLC, Pressure Vessel
Color: Customer's Requirements Advantage: Full Automatic
Certification: ASME CE, ASME CE Key Selling Points: Easy To Operate
High Light:

Pressure Vessel Vulcanization Tank

,

Vulcanization Tank 2000mm

,

2600mm Rubber Tyre Pressure Vessel

High Quality Pressure Vessel Vulcanization Tank For Rubber And Tyre
1. Product Introduction:


The vulcanizer is mainly used for rubber tire retreading, reclaimed rubber desulphurization, wire, cable, tape, rubber rollers and other rubber products vulcanization.Styrene-butadiene rubber thermoplastic refining, wood, Chinese medicine sterilization, oxidation of aluminum products, carbonization of bamboo products, It also widely used in the gypsum and its products and other materials autoclaving.



TinWing can provide a key solution according to the specific needs of your process or equipment control for you . Engineers ,electrical engineers as well as service team in TinWing control department are experts in both the full system and the upgrading . When you purchase a TinWing control system meaning that you received a key overall solution .



The Automatic rubber belt vulcanizer is a pressure vessel with speed open door. Its openings sealed with inflatable silicone ring or internal pressure self-tight rubber pad. Mechanical or manual gearing is used to lock and open the lid, reasonable structure,convenient operation, good sealing performance, the temperature in the tank is uniform,furthermore, complete safety accessories(equipped with safety interlock device).

 Size Information
Item
800
1200
1500
1700
2000
2600
Inner diameter(mm)
800
1200
1500
1700
2000
2600
Canister length(mm)
22000
3000
3000
4000
5000
10000
Number of lid sawtooth
12
12
14
14
16
24
thickness of lid (mm)
10
10
10
10
16
14
Thickness of the tank body(mm)
10
10
10
10
12
14
Working pressure(MPa)
0.8
0.8
0.8
0.8
0.8
0.55
Dimensions(mm)
(length*width*height)
22766*1445
*1170
4010*1575
*1670
3960*2150
*2050
4925*2162
*2070
6200*2590
*2424
11722*3360
*4136
Weight(Kg)
5580
2017
2950
3835
6500
16775
