Product Details:
|
| Place Of Origin: | Shandong, China | Brand Name: | HHS |
|---|---|---|---|
| Model Number: | XQL-120 | Voltage: | 220V /380V /440V |
| Dimension(L*W*H): | 2300X1500X2530 | Certification: | CE,ISO9001 |
| Warranty: | 1 Year | Type: | Rubber Cutting Machine |
| Weight: | 2000kg | Power(W): | 11KW |
| Product Name: | High Quality Vertical Rubber Bale Cutter | Time Of Blade Cutting: | 13-16 |
| High Light: | Guillotine Floor Rubber Cutting Machine,XQL 8T Rubber Cutting Machine,Single Knife Guillotine Cutting Machine |
||
Usage:
This rubber bale cutter is mainly used to cut the natural rubber,synthetic rubber and other plastic materials,especially it is suitable to be installed near the rubber mixer to cut small pieces of rubber.
Features of rubber bale cutter:
1.This rubber bale cutter mainly consists of cutting knife,frame,cylinder,base,auxiliary table,sydraulic system and electric system.
2.The nylon plate is installed on the base under the cutting knife for protecting the edge of the cutting knife.
3.When cutting the raw rubber,put the raw rubber under the cutting knife,the press the start button,the knife can cut the rubber.
5.Two limited switches are installed on the frame to control the reversal valve to change the movement direction of the knife,at the same time,it protects the cover of the cylinder.
Technical Information:
| Type | XQL-80 | XQL-160 |
| Width (mm) | 660 | 1000 |
| Stroke (mm) | 680 | 680 |
| Diameter of the piston (mm) | 150 | 150 |
| Time Taken by the Stroke (second) | 16~25 | 10~16 |
| Power (KW) | 5.5 | 5.5 |
| Overall Dimension (LxWxH) | 1900×720×2580 | 2000×500×3000 |
| Weight (kg) | 1500 | 2000 |
Qingdao Honghesheng Industry Co., LTD, manufacturer of rubber machine,which is located in the west coast of Qingdao economic district, with 10 million registered capital. The company covers an area of 5000 square meters with 26 professional and technical staffs and 5 senior engineers. The technical staffs have working experience in large tire enterprise who can design more suitable equipment for the customer as for tire production process. Also they can provide new factory site planning and other services.
The company’s main products are: Rubber kneader, rubber mixing mill, rubber sheet cooling machine, inner tube production line,tyre production line, vulcanizing press, waste tyre recycling plant…
welcome to visit our factory!
