EPDM Mesh Belt Film Batch Off Cooling Machine 700mm

EPDM Mesh Belt Film Batch Off Cooling Machine 700mm
EPDM Mesh Belt Film Batch Off Cooling Machine 700mm EPDM Mesh Belt Film Batch Off Cooling Machine 700mm

Large Image :  EPDM Mesh Belt Film Batch Off Cooling Machine 700mm

Product Details:
Place of Origin: CHINA
Brand Name: HHS
Certification: CE ISO
Model Number: XGP-600/ XGP-900
Payment & Shipping Terms:
Minimum Order Quantity: 1 set
Price: USD:8000-60000 /SET
Packaging Details: wood package /20-40 container
Delivery Time: 35 working days
Payment Terms: L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability: 100 sets/month

EPDM Mesh Belt Film Batch Off Cooling Machine 700mm

Description
Place Of Origin: Shandong, China Model Number: XPG-600
Condition: New Brand Name: HHS
Voltage: 380V Suitable Sheet Size: 600-900mm
Dimension(L*W*H): 14850/18600*1880*3100mm Weight: 20T
Certification: ISO9001:2008 Warranty: One Year
After-sales Service: Engineers Available To Service Machinery Overseas Power: 20-26kw
Color: As Customer Require Line Speed: 5~25m/min
Maximum Cutting: 450mm Length Tolerance Of: <3mm
High Light:

Batch Off Cooling Machine 700mm

,

EPDM batch off cooling machine

,

EPDM Mesh batch off machine

EPDM Mesh Belt Film Cooling machine Line



1. Usage:

This batch-off machine is mainly used for down stream line equipment of internal mixer and cooling sheet ,it can cool the rubber sheets from high temperature to room temperature ,and applicable to any kinds of rubber materials.





2. Features:

This machine consists of take-off, print, slitting, transportation, immersing insulation, lifting, sheet cooling fan with low power, low noise, high wind pressure and large capacity. This machine adopts PLC auto control system and measures with electric balance. It has two kinds of installation, floor type and high-frame type, for the user to choose.



3. Advantages:

1. The operations of coating separant,air cooling,drying,cutting and wig-wag stacking are set in one single cooling machine,achieving continuous operation with higher efficiency.

2. Rubber sheet are soaked before coating separant ,so the coating effect is very good and no enviromental pollution.

3. Time of air cooling process for rubber sheet cooling is set very long, so cooling effect is excellent.

4. Rubber sheet can be cut into certain length during operation and the cutting length is adjustable.

5. With PLC control and frequency-control speed regulation,it is very convenient to control the whole working process.



4. Technical Parameters:

Version / parameter XPG-600-700 XPG-800-900
Lab specification (4-12)× 600-700mm (4-12)× 800-900mm
Front take-away coneyor belt max linear velocity 400m/min 400m/min
Rubber strip hanging barwoving speed 0.117-202m/min 400m/min
Axial Fan 0.37kw 5760m 3 /h 0.37kw 5760m 3 /h
Swing range and frequancy 1.3m 10-16 twice/min 1.3m 10-16 twice/min
Rubber strip temperature after cooling ≤ Room temperature add 5 degree more ≤ Room temperature add 5 degree more
Speed -adjusting frequency motor of lifting swing edvice XWD1.5-3-1/11 XWD7.5-7-1/43
Speed -adjusting frequency motor of rubber swing edvice XWD1.5-3-1/87 XWD1.5-3-1/87
Rubber bar pitch 160 or 101.6 160 or 101.6
Max. hanging height of rubber strip 1400mm 1400mm







EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 0EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 1EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 2EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 3EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 4









EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 5EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 6EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 7

EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 8EPDM Mesh Belt Film Batch Off Cooling Machine 700mm 9
